5 Marla House Design in Pakistan | Floor Plans & Ideas [2026]

The 5 marla plot is Pakistan’s most popular residential plot size, and it is not close. From DHA and Bahria Town to LDA Avenue, Johar Town, and virtually every new housing scheme launched in the last decade, millions of 5 marla plots form the backbone of urban Pakistani home ownership. If you own one, you are in the largest, most competitive, and most exciting category of home building in the country.

A great 5 marla house design in Pakistan is the difference between a cramped, dark box and a bright, comfortable home that fits a family of six with room to spare. Smart planning is everything at this size, because on a 25×45 ft plot, every single square foot is doing a job. The right 5 marla ghar ka naksha extracts genuine comfort, light, and even luxury from a compact footprint, while a poor one wastes space you can never get back.

This complete 2026 guide covers everything you need: plot dimensions and coverage rules, single and double storey layouts, room-by-room floor plans with real dimensions, front elevation styles, society-specific design for DHA and Bahria Town, full construction costs in PKR, the approval process, and how to get your own custom design..

What is a 5 Marla Plot? Dimensions & Coverage Rules

Before any 5 marla house plan in Pakistan makes sense, you need to understand exactly what you are working with: the dimensions, the legal coverage limits, and how many floors you can build.

5 Marla Plot Size & Dimensions in Pakistan

A standard 5 marla plot in Pakistan measures 25×45 ft, totaling 1,125 sq ft. This is the dimension you will find across most LDA schemes, Bahria Town, and newer societies. Variations exist: DHA plots are sometimes 25×50 ft (1,250 sq ft), while some older LDA schemes use 20×45 ft or 25×40 ft. Always confirm your plot’s exact dimensions from your allotment documents before design begins, because even a five-foot difference changes the layout meaningfully.

Here is how the marla system converts, which helps you compare your plot against other sizes:

Note: this table uses the standard Punjab marla of 225 sq ft. Older Karachi and KPK measurements sometimes use 272 sq ft per marla, so confirm your local standard.

Ground Coverage & FAR Rules for 5 Marla in Pakistan

You cannot build on 100% of your plot. Coverage rules, setbacks, and FAR (floor area ratio) reserve open space for light, air, and approval compliance:

• LDA bylaws (Lahore): typically allow high ground coverage on 5 marla plots with a small mandatory front space and rear open area; the exact percentage depends on the scheme.
• KDA / SBCA regulations (Karachi): coverage and setback rules vary by scheme and are enforced through SBCA scrutiny.
• CDA rules (Islamabad): stricter, with defined ground coverage ratios, setbacks, and mandatory open spaces per sector.
• DHA guidelines: each DHA city publishes its own coverage and setback rules on top of the municipal bylaws.
• Bahria Town: has its own specific coverage and setback requirements designed to maintain the community’s visual standard.

A PCATP registered architect designs your home to extract every legally usable foot while staying fully compliant, which is exactly where professional design pays for itself on a small plot.

How Many Floors Can You Build on 5 Marla?

In most jurisdictions, the standard allowance on a 5 marla plot is ground plus two floors (a double-storey home plus a mumty), within a height limit commonly around 38 to 40 feet. Triple-storey construction is permitted in some societies and schemes but not all, and it triggers stricter structural requirements. Basements are generally allowed subject to setback, waterproofing, and structural rules, and they are excluded from the height calculation. Because floor and height allowances vary by authority and society, your architect confirms exactly what your specific plot permits before drawing a single line.

With the rules clear, here is how those floors can actually be arranged.

5 Marla House Design Options: Single & Double Storey

Your first big decision is how many storeys to build. This single choice shapes your budget, your room count, and your home’s resale value.

5 Marla Single Storey House Design

A 5 marla single storey design puts all your living on one level. It is best for elderly families who want stair-free living, for owners on a tighter budget, or for those planning to add a floor later.

A typical single-storey 5 marla layout delivers:

• 2 to 3 bedrooms (one master with attached bath, one or two standard)
• A drawing room at the front for guests
• A combined lounge and dining space
• A kitchen, commonly 8×10 ft
• 2 bathrooms
• A car porch and small rear courtyard

Pros: lower construction cost, faster build, no stairs, simpler maintenance. Cons: fewer rooms, lower resale value than double storey, and you consume your entire ground coverage for a single floor. Design tip: even if you build single storey now, design the foundations and columns for two floors, so future expansion costs nothing extra in structure.

5 Marla Double Storey House Design (Most Popular)

The 5 marla double storey design is by far the most popular configuration in Pakistan, and for good reason: it roughly doubles your covered area on the same land, allows proper zoning between guest and family spaces, and significantly improves resale value. With land prices far outpacing construction costs in every major city, double storey is the financially rational choice.

A well-designed double storey 5 marla ghar ka naksha typically arranges as follows:

Ground Floor:

• Drawing room (12×14 ft) at the front, ideally with a separate guest entry
• One bedroom (12×12 ft) with attached bath
• Lounge / family room connecting to the kitchen
• Kitchen (8×10 ft) with an optional small store
• Powder room for guests
• Car porch for one car, plus a small rear courtyard for light and ventilation

First Floor:

• Two to three bedrooms (master 12×14 ft, standard 10×12 ft), each with attached bath where possible
• A family lounge or TV area
• An optional kitchenette for joint-family setups

Mumty Level:

• Stair room plus an optional store or servant quarter
• A usable rooftop terrace for evening sitting and summer use

Staircase placement is the hidden decision that makes or breaks a 5 marla home. A well-positioned stair (often L-shaped against a side wall) lets both floors function semi-independently and keeps circulation tight, freeing space for actual rooms. This is the single most common area where template plans fail and custom design wins.

5 Marla Triple Storey House Design

A triple storey 5 marla home (where the society permits it) is primarily an income play. The ground floor can serve as a rental unit or shop-cum-flat while upper floors house the family, or all three floors can be rented separately. Triple storey demands a stronger structural design, deeper foundations, and careful column planning from the ground up, and it requires specific LDA, KDA, or CDA approval for the additional floor. It suits owners in high-rental-demand areas who want their plot to generate monthly income, but it is not permitted in every society, so confirm before planning.

5 Marla House Design with Basement

Is a basement possible on 5 marla? Generally yes, subject to society and municipal rules. LDA, for instance, allows basement construction with specific setback and structural requirements, and basements are excluded from height calculations. Common 5 marla basement design uses include storage, a car park to free up ground-level space, a home theater or family room, or even a separate rental unit. Basements add meaningful structural and waterproofing cost, typically Rs. 8 to 15 lakh depending on depth and finish, so we always model the cost-per-usable-foot against simply building up. In high water-table areas of Karachi and parts of Lahore, basement feasibility must be confirmed by soil testing first.

Once you have chosen your storey configuration, the real craft begins: arranging the rooms.

5 Marla House Floor Plans: Room-by-Room Guide

A great 5 marla floor plan in Pakistan is won or lost room by room. Here are the dimensions and design principles that make each space work on a compact plot.

Drawing Room Design for 5 Marla House

The drawing room (baithak) is your home’s face to guests. Ideal dimensions run 12×14 ft to 14×16 ft, placed at the front of the house for guest access, ideally with its own entry so visitors never pass through your private family areas. Design tips: keep furniture layout open against the walls, use a large window for natural light, and let a well-designed false ceiling with layered lighting set the tone. On 5 marla, a separate drawing room is a genuine trade-off against bedroom space, so decide early whether you host enough to justify it or prefer a combined drawing-dining arrangement.

Lounge / Family Room in 5 Marla House

The lounge is where your family actually lives. The big choice is combined lounge-kitchen (open plan) versus separate (closed plan). Open-plan layouts make a 5 marla home feel dramatically larger, improve light flow, and suit modern living, which is why they dominate new DHA and Bahria designs. Closed plans keep cooking smells and noise contained, which many traditional families prefer, especially for heavy desi cooking. A common compromise is a partially open kitchen with a serving counter.

Bedroom Layout in 5 Marla House

Bedroom planning decides whether your home feels generous or tight:

• Master bedroom: 12×14 ft minimum, with attached bath and ideally a small wardrobe area
• Standard bedrooms: 10×12 ft, comfortable for a bed, wardrobe, and study desk
• Bathrooms: attached baths add comfort and resale value; shared baths save space

The 3-bed versus 4-bed decision is the defining layout question on 5 marla. A 3-bed plan gives larger, more comfortable rooms; a 4-bed plan suits bigger families but shrinks each room and often forces shared bathrooms. There is no universally right answer; it depends entirely on your family, which is exactly why a custom naksha beats a template.

Kitchen Design in 5 Marla House

The kitchen works hardest in a Pakistani home. Ideal size runs 8×10 ft to 10×12 ft. The two main layouts are L-shaped (efficient, opens to the lounge, popular in modern homes) and straight / single-wall (space-saving, good for narrow kitchens). Wherever space allows, add a small store room or pantry off the kitchen, invaluable for bulk grocery storage and keeping countertops clear. Thoughtful kitchen and interior planning at the design stage saves expensive rework later.

Servant Quarter & Car Porch in 5 Marla

Two practical essentials:

• Servant quarter: 8×8 ft to 8×10 ft, usually placed at the mumty level or rear, with its own access and a small attached bath where possible
• Car porch: single-car is standard on 5 marla; a double-car porch is possible but eats significantly into front space and usually requires compromise elsewhere
• Boundary wall: designed to society specifications for height and finish, with the main gate proportioned to the porch

Staircase Design for 5 Marla House

The staircase is the unsung hero of 5 marla planning. Straight stairs are simplest but consume a long run of space. L-shaped stairs turn at a landing, fit neatly against a side wall, and are the most space-efficient choice for most 5 marla homes. Always design under-stair storage (a cupboard, a powder room, or a small store) so that space is never wasted. A well-placed stair can free up enough room for an entire extra bedroom, which is why it is never an afterthought in professional design.

With the plan resolved, attention turns to how your home greets the street: the front elevation.

5 Marla House Front Elevation Designs in Pakistan

The 5 marla front elevation is what neighbors see and what gives your home its identity. On a 25 ft wide front, every proportion counts. Here are the styles Pakistani homeowners request most in 2026.

Modern Contemporary Front Elevation

The dominant choice across DHA and Bahria Town. Modern elevations feature flat or concealed roofs, clean horizontal lines, large window openings, and asymmetric massing. Material palettes combine exposed brick, texture paint in grey and beige, wood-look cladding, and glass railings on the front terrace. A modern 5 marla house in Pakistan reads as crisp, confident, and forward-looking, and it photographs beautifully for resale listings.

Traditional Pakistani Front Elevation

The traditional elevation brings warmth and heritage: subtle arches, jharoka-style window projections, decorative parapet detailing, and finishes in warm stone, terracotta, and natural brick. This style remains popular in older city areas, Rawalpindi, Faisalabad, and among families who want their home to feel rooted rather than trend-driven.

Minimalist Front Elevation

Trending hard in 2026, the minimalist elevation strips ornament away entirely: flat clean surfaces, a restrained white-and-grey palette, hidden gutters, and disciplined window placement. Its appeal is low maintenance and timeless calm, and it suits the 5 marla width especially well because simplicity makes a compact facade feel composed rather than busy.

Mughal-Inspired Front Elevation

For clients who want heritage character with grandeur, the Mughal-inspired elevation brings pointed and scalloped arches, geometric jali patterns, and finishes in marble and carved stone. It is a bolder, more decorative choice that turns a 5 marla front into a statement, popular for those who love classical Pakistani architecture.

Key Elements of a Great Front Elevation

Whatever style you choose, five elements make or break the result:

• Main gate and boundary wall: proportioned to the facade, finished to society standards
• Entrance door: a quality main door sets the tone the moment guests arrive
• Window proportions and placement: balanced openings that bring light without compromising privacy
• Material selection: a disciplined palette of two or three materials reads far better than a cluttered mix
• Lighting: facade lighting transforms the elevation after dark, a detail most builders skip

A strong elevation respects the society’s character while expressing your taste. Speaking of societies, here is how 5 marla design adapts to Pakistan’s top addresses.

5 Marla House Designs for Top Pakistani Housing Societies

Where you build sets the rulebook. Each society controls elevations, materials, and approvals to protect its character, so a compliant 5 marla house design must be drawn to local guidelines from day one.

5 Marla House Design in DHA Lahore & Karachi

DHA is Pakistan’s premier address, and its design discipline shows. 5 marla DHA design guidelines govern front elevation character, approved materials, boundary wall height and finish, and gate placement, with each DHA city publishing its own construction bylaws. The DHA approval process adds a society building-control review before municipal requirements. Popular DHA 5 marla designs lean modern and contemporary, with clean facades in grey and wood tones. We maintain current bylaw files for DHA Lahore (all phases) and DHA Karachi, so your home is drawn to specification and clears review without redesign cycles.

5 Marla House Design in Bahria Town

5 marla Bahria Town design follows the development’s own guidelines, which regulate facade design, setbacks, and heights to maintain Bahria’s signature look. Some sectors carry specific architectural themes that designs must harmonize with. We design Bahria homes in Lahore, Karachi, and the Rawalpindi-Islamabad developments to clear society approval smoothly while still expressing your personal taste within the allowed range.

5 Marla House Design in Gulberg & Model Town Lahore

These established Lahore neighborhoods operate under LDA bylaws for coverage and setbacks. Gulberg and Model Town blend heritage and modern living, so both traditional neo-classical and clean contemporary styles work well here. Mature streetscapes set an elevated standard, and a thoughtful elevation helps your 5 marla home hold its own among larger established houses.

5 Marla House Design in Islamabad (F & G Sectors)

Islamabad’s planned, green context rewards clean, disciplined design. CDA regulations for 5 marla plots in the F and G sectors specify ground coverage, setbacks, and height limits, with formal scrutiny. Homes here increasingly integrate solar systems and energy-efficient glazing to handle both cold winters and hot summers, and minimalist and modern styles suit the city’s character best.

5 Marla House Design in Karachi (PECHS, Gulshan)

Karachi’s 5 marla homes in PECHS and Gulshan-e-Iqbal operate under KDA or SBCA rules depending on the scheme. The defining factor is climate: persistent heat and coastal humidity demand sea-breeze orientation, deep shading, cross-ventilation, and corrosion-resistant material choices. A heat-resilient 5 marla design stays comfortable and durable where a generic plan would struggle.

Society rules and design choices all feed into one number every owner wants to know: what will it cost to build?

5 Marla House Construction Cost in Pakistan 2026

Let us put real figures on the table. These are 2026 market ranges for building a 5 marla house in Pakistan, separate from the architect’s design fee.

Total Construction Cost for 5 Marla House (PKR)

Grey structure covers the foundation, columns, slabs, brickwork, and plaster: the bare bones. Finishing adds flooring, tiling, paint, fixtures, and woodwork. Turnkey means a complete, move-in-ready home. The luxury range reflects premium imported finishes, designer kitchens, and high-end fittings.

Cost Per Sq Ft for 5 Marla House Pakistan

Costing by covered area, 2026 rates run:

• Standard finish: Rs. 3,500 to 5,000 per sq ft
• Mid-range finish: Rs. 5,000 to 7,000 per sq ft
• Luxury finish: Rs. 7,000 to 12,000+ per sq ft

For a double-storey 5 marla home with roughly 1,900 sq ft of covered area, a standard finish at Rs. 4,500 per sq ft works out to about Rs. 85 lakh, which aligns with the turnkey table above.

Cost Breakdown by Construction Phase

Where your money actually goes, as a rough share of total construction cost:

• Foundation & structure: 25 to 30%
• Brickwork & plaster: 12 to 15%
• Roofing / RCC slabs: 10 to 12%
• Flooring & tiling: 10 to 12%
• Electrical & plumbing: 10 to 12%
• Doors, windows & finishing: 20 to 25%

Finishing is where budgets swing most, because the gap between standard and luxury tiles, fittings, and woodwork is enormous.

Factors Affecting 5 Marla Construction Cost

Five factors drive the variation: material quality (standard versus premium is the biggest swing), city and location (transport and labour differ across Lahore, Karachi, and Islamabad), labour rates, design complexity (basements, double-height spaces, and elaborate elevations cost more), and current material prices for cement, steel, and bricks, which have been volatile and should be confirmed at the time you build.

Architect Design Fee for 5 Marla House

The architect’s design fee is separate from construction cost. For a 5 marla home in 2026, design-only runs roughly Rs. 50,000 to 80,000, a full-service package Rs. 90,000 to 150,000, and full service with supervision Rs. 180,000 and above. This is one of the highest-return expenses in the entire project, because good design saves far more in avoided waste than it costs. For the complete fee breakdown across cities and scopes, see our detailed guide.

With budget understood, the final hurdle before construction is approval.

5 Marla House Map Approval Process in Pakistan

No 5 marla house map in Pakistan can be built legally until your local authority approves it. Here is how the process works in each jurisdiction.

LDA Approval for 5 Marla House (Lahore)

Required documents typically include the architectural drawing set signed by a PCATP registered architect, structural drawings for double-storey homes, ownership documents and latest fard, CNIC copies, society NOC where applicable, and the prescribed application forms. The process: drawings are submitted with scrutiny fees, the building section reviews against coverage, setback, and height bylaws, objections are issued for correction if any, and the approved map is released with the building permit. Timeline: a clean professional submission typically clears in 4 to 8 weeks. Government scrutiny and approval fees are charged separately on covered area.

KDA Approval (Karachi)

In Karachi, approvals run through KDA for its own schemes or the Sindh Building Control Authority (SBCA) for most of the city, and knowing which governs your plot is step one. The document list mirrors Lahore’s, with SBCA paying particular attention to structural safety. Typical timelines run 6 to 12 weeks depending on scheme and completeness.

CDA Approval (Islamabad)

CDA runs the most formalized process, with sector-wise coverage, FAR, and height rules and thorough scrutiny. Submissions go through CDA’s building control directorate with architect-signed drawings, ownership records, and fees. Clean submissions typically clear in 6 to 10 weeks, and drawings prepared by architects experienced with CDA standards clear scrutiny noticeably faster.

DHA & Bahria Town Approval Process

Society plots carry a dual process: first, society building-control approval against DHA or Bahria Town’s own architectural guidelines (elevation, boundary wall, setbacks), then any municipal authority requirements that apply. We prepare society-format submissions and manage both layers so your 5 marla map clears without redesign.

Once approved, your home is ready to build. Here is how we can take you from plot to completed design.

Our 5 Marla House Design Services

Crest Design Studio specializes in getting the most out of Pakistan’s most popular plot size.

What We Provide for Your 5 Marla House

Every 5 marla engagement includes:

• Complete drawing set: dimensioned floor plans, front and side elevations, sections, roof plan, and site plan
• 3D exterior and interior rendering so you see your home before building
• Structural drawings coordination with a registered structural engineer
• LDA / KDA / CDA approval submission and objection handling
• Optional construction supervision through to handover

Our 5 Marla Design Process (5 Steps)

We follow a clear five-step path: (1) consultation and site visit to understand your family and plot, (2) concept floor plans with two to three layout options, (3) design development with 3D visualization and your revisions, (4) authority approval submission and management, and (5) construction documents with optional supervision. Concept layouts reach you within about a week, and the full drawing set within 2 to 3 weeks. For the complete picture of our methodology,

Frequently Asked Questions: 5 Marla House Design Pakistan

Q1: What is the standard size of a 5 marla plot in Pakistan?

A standard 5 marla plot in Pakistan measures 25×45 feet, totaling 1,125 square feet. Dimensions vary slightly by society: DHA plots are sometimes 25×50 ft (1,250 sq ft), while some older LDA schemes use 20×45 ft or 25×40 ft. The marla itself is 225 sq ft in standard Punjab measurement, though older Karachi and KPK schemes sometimes use 272 sq ft per marla. Always confirm your exact plot dimensions from your allotment documents before starting design, since even a small difference affects the layout.

Q2: How many bedrooms can fit in a 5 marla double storey house?

A well-designed 5 marla double storey house comfortably accommodates 3 to 4 bedrooms. The ground floor typically has one bedroom with attached bath alongside the drawing room, lounge, and kitchen, while the first floor holds two to three bedrooms with a family lounge. A 3-bedroom plan gives larger, more comfortable rooms, while a 4-bedroom plan suits bigger families but reduces room sizes and often means shared bathrooms. The right choice depends on your family, which is exactly why a custom naksha outperforms a template plan.

Q3: What is the construction cost of a 5 marla house in Pakistan 2026?

In 2026, construction cost for a 5 marla house ranges from Rs. 25 to 35 lakh for grey structure only, Rs. 45 to 65 lakh for grey structure plus finishing, and Rs. 65 to 90 lakh for a complete standard-finish turnkey home. Luxury finishes with premium materials can push the total to Rs. 90 lakh to 1.5 crore and beyond. Cost per square foot runs Rs. 3,500 to 5,000 for standard finish and up to Rs. 12,000+ for luxury. These figures are separate from the architect’s design fee and depend heavily on material prices at the time you build.

Q4: Can I build a basement in a 5 marla house in Pakistan?

Yes, basements are possible on 5 marla plots, subject to society and municipal rules. LDA permits basement construction with specific setback and structural requirements, and basements are excluded from height calculations, which makes them attractive for adding usable area. Common uses include storage, car parking, a home theater, or a separate rental unit. Basements add roughly Rs. 8 to 15 lakh to construction cost depending on depth and finish. In high water-table areas of Karachi and parts of Lahore, soil testing is essential before confirming basement feasibility.

Q5: How long does it take to design and build a 5 marla house?

The full journey typically runs as follows: design takes 2 to 3 weeks from brief to final drawings, regulatory approval (LDA, KDA, CDA, or society) takes 4 to 8 weeks, and construction takes 8 to 14 months depending on scope, finishes, and how consistently funds and labour are available. Starting the design and approval process well before you plan to break ground keeps the overall timeline on track. Rushed construction almost always costs more and delivers less, so building in realistic time buffers is wise.

Q6: What design style is best for a 5 marla house in Pakistan?

Modern contemporary is the most popular style in 2026, especially in DHA and Bahria Town, thanks to its clean lines, large windows, and crisp grey-and-wood palettes. Traditional designs with arches and warm finishes remain popular in older city areas and among families wanting a rooted aesthetic. Minimalist designs are trending fast for their low-maintenance, timeless appeal, and they suit the compact 5 marla width especially well. The best style is the one that matches your taste, your society’s guidelines, and your maintenance appetite.

Q7: Do I need an architect for a 5 marla house in Pakistan?

While not always legally required on small plots, hiring a PCATP registered architect for a 5 marla house is one of the highest-return decisions you can make. Small plots punish design mistakes severely: a poorly placed stair or oversized bathroom can shrink an already compact home. A professional architect optimizes every square foot for space, light, and ventilation, ensures full compliance with LDA, KDA, or CDA bylaws, coordinates sound structural design, and produces approval-ready drawings that prevent costly authority objections and on-site rework.
